U3-3060SE
- Camera family
- SE
- Interface
- USB3
- Sensor type
- CMOS
- Frame / Line rate
- 161 fps
- Shutter
- Global Shutter
- Optical class
- 1/1.2"
- Resolution
- 2.30 MPix
- Mono / Color
- Mono / Color
- Data sheet 1
- U3-3060SE-C-HQ.pdf
- Data sheet 2
- U3-3060SE-M-GL.pdf
- 소비자가
- 별도문의
uEye SE
USB 3 5.0 Gbps, 1/1.2", Sony, 2.30 MPix, CMOS, 161.0 fps, IMX174, 1920 x 1200
?The U3-3060SE with Sony's 2.30 MPix sensor IMX174 (1920 x 1200 px) sets a new standard in terms of light sensitivity, dynamic range and colour reproduction. The USB 3 industrial camera provides excellent image quality with extraordinarily low-noise performance - at frame rates up to 161 fps (full resolution). The sensor is perfect for applications demanding excellent image quality even in low-light conditions as well as in industrial automation, quality assurance and robotics.
The U3-3060SE is available in both monochrome and colour variants.
This camera model is supported by IDS Vision firmware 2.0 and higher.
| Item number |
|
|---|---|
| Name | U3-3060SE |
| Camera family | SE |
| Interface | USB 3 |
| Interface-Speed | 5.00 Gbps |
| Sensor type | CMOS |
| Sensor manufacturer | Sony |
| Frame rate @ resolution max. | 161 fps |
| Resolution (h x v) | 1920 x 1200 |
| Optical Area | 11.251 mm x 7.032 mm |
| Shutter | Global Shutter |
| Optical class | 1/1.2" |
| Resolution | 2.30 MPix |
| Pixel size | 5.86 μm |
| IP code | IP30 |
| Product Life Cycle | Series |
