uEye XS

Camera family
Sensor type
Frame / Line rate
15.0 fps
Rolling Shutter
Optical class
5.04 MPix
Mono / Color
Mono / Color
Data sheet 1
uEye XS USB 2 0.5 Gbps, 1/4", OmniVision, 5.04 MPix, CMOS, 15.0 fps, OV5640, 2592 x 1944
Very small, really easy, just ingenious.

The small, smart XS with triggered autofocus and many other auto functions combines the easiness and comfort of a consumer camera with the scope of industrial applications. The XS can easily be integrated thanks to its USB 2.0 interface and Mini B USB 2.0 connector. Equipped with OmniVision’s 5.04 MPix CMOS sensor and a pixel size of 1.4 μm the camera delivers excellent images quality and accuracy in colour reproduction ? even in the harshest ambient light conditions.

The camera is the ideal choice for all applications that required a small yet smart camera with a great range of features. Due to its lightweight, compact design, 15.0 fps at full resolution (2592 x 1944 pixels) and integrated power supply, the XS is perfect for ATM, kiosk and embedded systems as well as medical engineering.

This camera model will be supported beginning with IDS Software Suite 4.92.

Item number
  • AB02716
Name uEye XS
Camera family XS
Interface USB 2
Interface-Speed 0.47 Gbps
Sensor type CMOS
Sensor manufacturer OmniVision
Frame rate @ resolution max. 15.0 fps
Resolution (h x v) 2592 x 1944
Optical Area 3.629 mm x 2.722 mm
Shutter Rolling Shutter
Optical class 1/4"
Resolution 5.04 MPix
Pixel size 1.40 μm
IP code IP30
Product Life Cycle Series
