UI-1490LE
- Camera family
- LE
- Interface
- USB2
- Sensor type
- CMOS
- Frame / Line rate
- 3.2 fps
- Shutter
- Rolling Shutter
- Optical class
- 1/2"
- Resolution
- 10.55 MPix
- Mono / Color
- Mono / Color
- Data sheet 1
- UI-1490LE-C-HQ.pdf
- Data sheet 2
- UI-1490LE-M-GL.pdf
- 소비자가
- 별도문의
uEye LE
USB 2 0.5 Gbps, 1/2", ON Semiconductor, 10.55 MPix, CMOS, 3.2 fps, MT9J003, 3840 x 2748
The UI-1490LE with the 10 megapixel CMOS sensor (MT9J003STM/STC) from ON Semiconductor delivers every detail in top image quality at a resolution of 3840 x 2748 pixels. The integrated scaler allows you to select any image size you require. The sensor also provides horizontal and vertical binning for contrast enhancement as well as subsampling for fast preview modes.
Full HDTV and quad HDTV resolutions are also possible.
Extension ring CS-mount to C-mount
The CS-mount version comes with an extension ring which enlarges the flange back distance by 5 mm. This allows use of C-mount lenses with the camera.
| Item number |
|
|---|---|
| Name | UI-1490LE |
| Camera family | LE |
| Interface | USB 2 |
| Interface-Speed | 0.47 Gbps |
| Sensor type | CMOS |
| Sensor manufacturer | ON Semiconductor |
| Frame rate @ resolution max. | 3.2 fps |
| Resolution (h x v) | 3840 x 2748 |
| Optical Area | 6.413 mm x 4.589 mm |
| Shutter | Rolling Shutter |
| Optical class | 1/2" |
| Resolution | 10.55 MPix |
| Pixel size | 1.67 μm |
| IP code | IP30 |
| Product Life Cycle | Series |
