UI-3060SE
- Camera family
- SE
- Interface
- USB3
- Sensor type
- CMOS
- Frame / Line rate
- 166 fps
- Shutter
- Global Shutter
- Optical class
- 1/1.2"
- Resolution
- 2.35 MPix
- Mono / Color
- Mono / Color
- Data sheet 1
- UI-3060SE-C-HQ.pdf
- Data sheet 2
- UI-3060SE-M-GL.pdf
- 소비자가
- 별도문의
uEye SE
USB 3 5.0 Gbps, 1/1.2", Sony, 2.35 MPix, CMOS, 166.0 fps, IMX174, 1936 x 1216
The UI-3060SE with Sony's 2.35 MPix sensor IMX174 (1936 x 1216 px) sets a new standard in terms of light sensitivity, dynamic range and color reproduction. The USB 3 industrial camera provides excellent image quality with extraordinarily low-noise performance - at frame rates up to 166 fps (full resolution). The sensor is perfect for applications demanding excellent image quality even in low-light conditions as well as in industrial automation, quality assurance and robotics.
The UI-3060SE is available in both monochrome and colour versions.
This camera model will be supported beginning with IDS Software Suite 4.92.
Item number |
|
---|---|
Name | UI-3060SE |
Camera family | SE |
Interface | USB 3 |
Interface-Speed | 5.00 Gbps |
Sensor type | CMOS |
Sensor manufacturer | Sony |
Frame rate @ resolution max. | 166 fps |
Resolution (h x v) | 1936 x 1216 |
Optical Area | 11.345 mm x 7.126 mm |
Shutter | Global Shutter |
Optical class | 1/1.2" |
Resolution | 2.35 MPix |
Pixel size | 5.86 μm |
IP code | IP30 |
Product Life Cycle | Series |
