UI-5490RE PoE
- Camera family
- RE
- Interface
- Ethernet
- Sensor type
- CMOS
- Frame / Line rate
- 6.1 fps
- Shutter
- Rolling Shutter
- Optical class
- 1/2"
- Resolution
- 10.55 MPix
- Mono / Color
- Mono / Color
- Data sheet 1
- UI-5490RE-C-HQ_PoE_Rev_2.pdf
- Data sheet 2
- UI-5490RE-M-GL_PoE_Rev_2.pdf
- 소비자가
- 별도문의
uEye RE
Ethernet 1.0 Gbps, 1/2", ON Semiconductor, 10.55 MPix, CMOS, 6.1 fps, MT9J003, 3840 x 2748
The UI-5490RE PoE with the 10 megapixel CMOS sensor (MT9J003STM/STC) from ON Semiconductor delivers every detail in top image quality at a resolution of 3840 x 2748 pixels. The integrated scaler allows you to select any image size you require. The sensor also provides horizontal and vertical binning for contrast enhancement as well as subsampling for fast preview modes.
Full HDTV and quad HDTV resolutions are also possible. The PoE version also provides two additional general purpose I/Os (GPIOs). The power supply is provided by the screw-on, dust proof and splash water proof M12 circular connector.
| Item number |
|
|---|---|
| Name | UI-5490RE PoE |
| Camera family | RE |
| Interface | Ethernet |
| Interface-Speed | 1.00 Gbps |
| Sensor type | CMOS |
| Sensor manufacturer | ON Semiconductor |
| Frame rate @ resolution max. | 6.1 fps |
| Resolution (h x v) | 3840 x 2748 |
| Optical Area | 6.413 mm x 4.589 mm |
| Shutter | Rolling Shutter |
| Optical class | 1/2" |
| Resolution | 10.55 MPix |
| Pixel size | 1.67 μm |
| IP code | IP65/67 |
| Product Life Cycle | Series |
